Cioks SOL

Regular price €169.00

Cioks SOL Power Supply

SOL is the ultimate solution for bringing life to a small to medium-sized pedalboard setup, especially if you are using power-hungry pedals. SOL is the smallest mains-powered switch-mode power supply we make at CIOKS (no wall-warts here) and the no-frills design plus massive power will leave you free to focus on your creative spark.

Featuring the same 660mA at 9V DC per outlet and four switchable voltages on each outlet as its bigger brother CIOKS DC7, SOL is the most powerful small form-factor power supply available today with a total of 30 watts of DC power available.


  • CIOKS SOL has the same groundbreaking 1-inch profile (25,4mm) as CIOKS DC7
  • Ultra-low noise achieved by multistage filtering
  • 5 isolated DC-outlets, 6W each
  • 660mA at 9V on each outlet
  • 4 selectable voltages on each outlet • Total maximum power 30W
  • Mounting hardware for Pedaltrain and Templeaudio Boards included
  • Compatible with CIOKS GRIP v2.0 for drill-free mounting underneath Pedaltrain boards*
  • 9 Flex cables included
  • Designed in Denmark, assembled in Poland
  • 5-year worldwide warranty


  • Mains input: 100-240V AC universal
  • Outlet 1-5:
  • 9V DC / 660mA or 12V DC / 500mA or 15V DC / 400mA or 18V DC / 330mA each Total output power: max. 30W
  • Dimensions: 130x88x25,4mm (5.2x3.5x1.0”), excl. rubber feet
  • Weight: 400g (0.9lb)

Flex Cables

CIOKS offers a wide selection of different Flex cable types for connection your pedals to the power supply. Below you see a list of the included Flex cables with your unit:

What´s in the box

  • 3 x 1030 - Type 1 - 5,5/2,1mm DC plug, centre negative, L-shape, 30cm (black)
  • 2 x 1050 - Type 1 - 5,5/2,1mm DC plug, centre negative, L-shape, 50cm (black)
  • 1 x 2050 - Type 2 - 5,5/2,1mm DC plug, centre positive, L-shape, 50cm (red)
  • 1 x 4050 - Type 4 - 5,5/2,5mm DC plug, centre positive, L-shape, 50cm (green)
  • 1 x 1035 - Split Flex type 1 - 30 & 50cm (black)
  • 1 x 1533 - 3-way daisy chain Flex type 1, 30+30+50cm (black)1 x
  • SOL power supply
  • 1 x AC power cord (region specific)
  • 9 x Flex cables
  • Mounting hardware for Pedaltrain and Templeaudio boards
  • Product manual
  • 1 x Flex Guide
  • 1 x CIOKS sticker sheet

Split Flex should be used if you would like to power two pedals with the same voltage using only one outlet. In the same manner you should use the 3-way daisy chain if you wish to power three pedals of one outlet. For further information about Flex cables please have a look at the included Flex cable selection guide or visit CIOKS web site.

Cioks SOL User´s Manual (link to Cioks)
